Stickney: Correctly auditing your ballflight without technology

Published

on

One of the biggest advances in golf instruction, in my opinion, was the adoption (by the masses) of the “new ball-flight laws.” While this information was first identified in “The Search for the Perfect Swing” as well as “The Golfing Machine” books it was not truly taught in the mainstream by teachers until the last decade. In fact, there are still millions of golfers who are still in the dark as it pertains to how curvature is created.

Thankfully, launch monitors have become more popular and now most people have some type of ability to hit balls using Trackman, etc., and this has helped inform the masses as to what is really happening during the impact interval. In today’s article, I want to show you how to audit your ball-flight if you DO NOT have access to a launch monitor. And if you’ll ask yourself these few simple questions you will have a much better idea as to what is happening and why your ball is doing what it’s doing!

“The New Ball-Flight Rules”

  • The ball begins mostly in the direction of the face angle direction at impact (Face Angle)
  • The ball will curve away from the path with a centered hit on the face (Path)
  • The amount of curvature at the apex is mostly determined by the difference in direction between where the face points at impact and the direction of the path at impact (Face to Path)
  • The impact point on the clubface can render the above obsolete or exaggerate it depending on where it’s impacted on the face (Impact Point)

Now that you know and understand the rules, here’s how you audit your ball’s flight without a launch monitor present…

Find your Impact Point Before Making Any Other Judgements

Before we begin delving deeply into your ball’s flight, let’s first stop for a second and figure out what our impact bias is currently. Yes, everyone has an impact bias—some are more toe-based while others are more heel-sided. It’s just the way it works and it’s mega-important. If you don’t have control of your impact point then all else is moot.
In order to do so, first hit a few balls on a flat lie and spray the face with Dr. Scholl’s spray, then take a look at what you see on the face, where are the marks? I’m not asking you for perfection here, because if you hit it slightly on the toe or slightly on the heel then you’re ok.

However, if your average clustering of shots is extremely biased on the toe or the heel then stop and figure out WHY you are hitting the ball off-center. Until you can contact the ball in the center of the face (within reason) then you will not be able to control your ball’s curvature due to gear effect.

If your impact point clustering is manageable, then ask yourself these three questions to truly understand your ball’s flight…

Number 1: Where did the ball begin?

I want you to draw a straight line from your ball through your target as you see in the left photo in your mind so you now have a “zero” reference. If you need to create this visual on the practice tee then you can put a rope or some string on the ground between the ball and the target creating a straight line from the ball through the rope and onward to the target itself.

Now back to the shot above, as you can see at impact, this player’s ball started slightly LEFT of his target-line—as shown by the arrow in the left frame which depicts the face angle at impact. In the right frame, you can easily see the ball beginning a touch left right from the beginning.

The numbers prove what we discussed earlier

  • The face direction at impact was -2.8 degrees left of the target
  • The ball’s launching direction is -1.7 degrees left of the target

As we know the ball begins mostly in the direction of the face and since the face was left of the target the ball also began slightly leftward as well.

So by paying attention to your ball’s starting direction as it pertains to the “zero line” (or where you’re trying to go) you can guess where the face is pointing at impact.

Number 2: Which direction did the ball curve?

Now, take a second and look at the right frame: We see that the ball curved leftward which means the path had to be more rightward than where the face was pointing at impact. If the ball begins where you want it to start and curves the way you want then you have the face and path in the correct place!

If we want to audit the numbers just to be sure, then let’s take a deeper look:

Trackman shows that the club path was 1.9 degrees right of the target and we just saw that the face was -2.8 degress left of the target on this shot. With centered impact anytime the face direction at impact is left of the path the ball will curve leftward. The negative spin-axis of this shot of -7.9 tells us that the ball is moving to the left as well.

If you want the ball to curve to the left then the path must be further right than that and vice-versa for a fade…pretty simple, right?

Number 3: How Much Did the Ball Curve at The Apex?

Question three is an important one because it helps us to understand what our face to path relationship is doing.

Curvature is created when the face and path point in different directions (with a centered hit) and the bigger the difference between the face and path direction the more the ball will curve…especially as you hit clubs with lower lofts.

Every player wants to see a certain amount of curvature. Some players want very little curve, thus their face to path numbers are very close together while others want more curve and the face to path numbers are larger. It does not matter what amount of curvature you like to “see” as the player…all flights will work. Think Moe Norman on one extreme to Bubba Watson on the other.

To close…

First, you must hit the ball in the center of the face to have a predictable curvature if you hit it all over the face then you invoke gear effect which can exaggerate or negate your face to path relationship.

Second, where did the ball begin? Most players whom draw the ball fear the miss that starts at their target and moves leftward (as depicted in the photo above) this is a FACE issue. The face is left of the TARGET at impact and thus the ball does not begin right enough to begin at the correct portion of the target.

If you hit the ball and it starts correctly but curves too much from right to left then your path is to blame.

Third, if your ball is curving the correct direction then your path is fine, but if it’s doing something other than what you want and you are starting the ball where you want then your path is either too far left or right depending on which way the ball is curving.

Fourth, if your ball curvature at the apex is moving too much and your ball is starting where you want then your path is too far left or right of your face angle at impact exaggerating your face to path ratio. The bigger the difference between these two the more the ball curves (with a centered hit) with all things being equal.

Samples to view

This is a path issue…the ball began correctly but curved too much rightward. Don’t swing so much leftward and the face-to-path will be reduced and the ball will curve less.

This is a great push draw…the ball began correctly and curved the correct amount back to the target

This is a face issue at impact…the ball did not begin far enough to the right before curving back leftward and the target was missed too far to the left

Take your time when auditing your ball’s flight, and I believe you’ll find your way!
